Description
This hammer mill is an integrated unit combining a blower and a grinding chamber. The machine housing and the blower impeller are integrated within a single chamber, eliminating the need for a separate external blower or ductwork. Material is fed into the grinding chamber through the open hopper at the top, where high-speed, wear-resistant hammer blades impact, shear, and grind the material; Qualified powder is drawn by the negative-pressure airflow generated by the built-in blower and conveyed through the side elbow discharge port to the cyclone collection hopper, while coarse material remains in the chamber for repeated crushing until it meets specifications. The entire unit is shipped as a single, fully assembled unit; simply connect the motor, plug it in, and attach the dust collection and material collection system to begin production immediately.
Product Feature
- Integrated design for simple, hassle-free installation.
- Adequate negative-pressure airflow prevents screen clogging and mesh blockage.
- Sturdy construction with low operating and maintenance costs.
- Flexible, adjustable particle size settings covering the full range from coarse to fine.
- Sealed conveying system minimizes dust pollution.
Applicable Industries And Use Cases
- Edible mushroom processing plants, mushroom log production facilities:
- Small-scale processing plants, biomass fuel workshops:
- Large-scale livestock farms, small-scale feed processing facilities
- Organic fertilizer processing plants, horticultural growing media plants
Model Specifications
| Model | Power（KW） | Speed（r/min） | Output | Notes |
| 500 | 22 | 4200 | Determined based on the feed material and the desired particle size | Includes connecting pipes,dust collectors, cyclones, filter bags, the main unit, supports, etc. |
| 600 | 37 | 4200 | ||
| 800 | 55 | 2700 | ||
| 1000 | 90 | 2200 |
